– Conform to new IMO regulation
– NSR’s own FFC and FPC used
– Real monitoring software available for easy check
– Flexible configuration for either VDR or S-VDR
– Linux O/S used in firmware of VDR system
– Large size color LCD with touch screen operation
– Data interface to BAM System
– Type approval with DNV (MED) and CCS
- NVR-9000 VDR is designed to comply with the latest IMO rules of MSC.494 (104), IMO MSC.302 (87), IEC 61996-1, IEC 62923-1, IEC 62923-2, IEC 62288.
- Store data for min 30 days/720 hours in LRU of Data Acquisition Unit.
- Record image of two radars and two ECDIS.
- Three separate channels for audio input: - One for up to 4 microphones - One for up to 4 microphones - One for 2 VHF audio
- As standard configuration, the following ports are provided: - Serial port×24 ch (8 at DAU and 16 at DEU) - Digital port×64 ch (DEU) - Analog port×8 ch (DE
- PC software available for playback & real-time monitoring
